SKU: MT120EVOPS.
Category : .

CyclonePro™

MT120EVOPS



Description:

* Fully Installed Suggested Retail Price based on a powerpoint being within close proximity, metro install, door moves freely and is in good condition​
* Actual price is provided by the professional dealer and may therefore vary from the suggested retail price.

CyclonePro is Merlin's most powerful garage door opener for sectional garage doors. It's the safest solution for powering cyclone, wind rated and heavy custom doors. Suited for Sectional Garage Doors and compliant to Australian & New Zealand Standards. It also comes with 5 Year Warranty for complete peace of mind and Merlin Security+2.0 encryption rolling code technology for operation under all environment conditions and greater distance than ever before.

  • Product Features
  • Specifications
  • Downloads

General

  • 24V DC motor with thermal overload protection
  • Input voltage: 240V AC
  • Rated door area up to 20m²
  • Max door weight: up to 286kg
  • Max peak pulling force: 1200 N
  • C-rail with chain drive
  • 433.30, 434.54, 433.92 MHz AM radio with Security+2.0 encrypted rolling code technology.
  • Up to 64 memory registers
  • Courtesy light: LED
  • Min headroom required: 30mm

Door Specs

  • Maximum lifting under spring tension = 20kgs
  • Suitable for steel and timber spring balanced doors
  • Up to 286kg mass weight when beams are installed

Door Opening and Closing Times

  • Door opening times: 18 seconds (normal), 29 seconds (slow)
  • Door closing times: 22 seconds (normal) 31 seconds (slow)
  • Based on a 2.4m high door

Door Height

  • Total door area 20m²
  • Single dwelling



Optional Accessories
